8mm, 12mm, 16mm, 25mm, 35mm and 50mm Focal Length Lenses
The MEGA6™ Series Lens Kit includes six 6 megapixel 2/3″ format fixed focal length lenses (170 lp/mm), ranging from 8mm to 25mm. This kit conveniently packages all six lenses in one compact, portable, impact and static resistant case for easy testing.
MEGA6™ Series Lenses
| Part Number | Lens Format | Focal Length (mm) | Iris Range | MOD (mm) | |
|---|---|---|---|---|---|
| GM6HR38014MCN | 2/3" | 8mm | f/1.4-16 | 100 | |
| GM6HR31214MCN | 2/3" | 12mm | f/1.4-16 | 150 | |
| GM6HR31614MCN | 2/3" | 16mm | f/1.4-16 | 200 | |
| GM6HR32514MCN | 2/3" | 25mm | f/1.4-16 | 200 | |
| GM6HR33520MCN-1 | 2/3" | 35mm | f/F2 - Close | 300 | |
| GM6HR35028MCN-1 | 2/3" | 50mm | f/F2.8 - Close | 500 |
